Features:
|
Item Name: |
12MM-240LED-SMD3528 |
Operating Voltage Available: Unit: VDC |
12 VDC or 24VDC |
|
Cut Length: |
Every 3 LED(12V) Every 6 LED(24V) |
Max Operating Current: Unit: mA |
1.6A/M |
|
LED QTY: |
240LED/M |
Power Consumption: Unit: W |
19.2W/M |
|
LED Chip: |
SMD3528 |
PCB Width: |
8MM |
|
PCB Material: |
Double-side FPC |
Operating Temperature: |
0°C - + 40°C |
|
Length: |
5M or 10M / Reel |
Brightness per LED: |
7-8LM |
|
Waterproof Grade: |
IP20( IP54,67,68 Optional) |
||
² More Detail:
1. White, Warm White, Blue, Red, Green, Yellow etc, all colors are available
2. Packing Specification: Anti-Electrostatic Polybag or Blister card
3. IP20 Length is 5M/10M one reel, IP54, IP67, IP68 is 5M/one reel
4. Warranty Time: 36 months
5. Terms of payment: T/T, Western Union, PayPal and Escrow
6. Usage: suitable for backlit cabinets, ceiling decoration, defining objects or furniture and for external landscaping designs
Ø Parameter:
|
Part Number |
Input Voltage |
LED Type |
Power |
Tc(K)/nm |
Strip Width |
PCB Color |
Luminous |
Continuous |
Cuttable |
Lifespan |
|
12MM-240LED-SMD3528 |
12VDC |
3528 |
96W |
5700K-6500K |
12mm |
white |
1920LM |
5M |
Every 3LED |
30,000H |
|
12MM-240LED-SMD3528 |
12VDC |
3528 |
192W |
5700K-6500K |
12mm |
white |
1920LM |
10M |
Every 3LED |
30,000H |
|
12MM-240LED-SMD3528 |
24VDC |
3528 |
96W |
5700K-6500K |
12mm |
white |
1920LM |
5M |
Every 6LED |
30,000H |
|
12MM-240LED-SMD3528 |
24VDC |
3528 |
192W |
5700K-6500K |
12mm |
white |
1920LM |
10M |
Every 6LED |
30,000H |
Ø Waterproof Type:
Ø Application :
1. Decorative lighting for exhibition shelves, advertising light box and hotel etc;
2. Backlight for edge lighting/signage;
3. Holiday decorative lights, residential and outdoor lighting;
4. Bridge, garden, road and car lighting etc;
5. Long-distance project but with inconvenient wiring;
Ø Note:
